Fiber Optic Laryngoscopes (Reusable)
Premium reusable fiber optic laryngoscope systems with LED illumination in the handle, engineered for superior visibility, durability, and infection-control compliance.
Fiber Optic Reusable Blades
- Enlarged 3.6mm diameter fiber optic bundle
- Complete Stainless Steel guaranteed for 2 years
- Engineered with removable fiber optic bundle for easy replacement of damaged bundles
- Autoclavable Light Guide, Tested to withstand over 4000 cycles
- Matt Finish to remove any reflection during intubation
- Compatible to All ISO Handle 7376-3
System Components
Fiber Optic Reusable Blades
Macintosh (0-5), Miller (00-4) and Flexi-Tip (McCoy) blades manufactured from high-quality stainless steel with matte finish.
LED Fiber Optic Handels
Available in Adult, Pediatric and stubby sizes with textured, non slip grip and long-life LED Technology.
ISO Compatibility
Fully compatible with ISO 7376 (Green System) allowing interchangeable blades and handles.
Fiber Optic Reusable Blades – Specifications
SIZE
- MAC 0
- MAC 1
- MAC 2
- MAC 3
- MAC 4
- MAC 5
- MILL 00
- MILL 0
- MILL 1
- MILL 2
- MILL 3
- MILL 4
OVERALL LENGTH
- 75 MM
- 92 MM
- 101 MM
- 133 MM
- 155 MM
- 172 MM
- 65 MM
- 75 MM
- 102 MM
- 155 MM
- 195 MM
- 205 MM
BLADE LENGTH
- 58 MM
- 72 MM
- 93 MM
- 110 MM
- 130 MM
- 150 MM
- 44 MM
- 54 MM
- 79 MM
- 131 MM
- 172 MM
- 182 MM
DISTAL WIDTH
- 9 MM
- 9 MM
- 13 MM
- 14.5 MM
- 15.5 MM
- 15.5 MM
- 10 MM
- 10 MM
- 10 MM
- 13 MM
- 13 MM
- 17 MM
Flexi-tip / Trupti blade (McCOY) FiberOptic Blades
- Enlarged 3.6mm diameter fiber optic bundle
- LED technology provides up to 40% more light than conventional halogen bulbs.
- Compatible with all ISO 7376 (Green System) handles.
- Matte finished blade surface reduces glare to enhance ease of intubation
- Engineered with a removable fiber optic bundle for easy replacement of damaged bundles.
- Ideal for EMS / Emergency Room.
Flexi-Tip (McCOY) FiberOptic Blades – Specifications
SIZE
- MAC 2
- MAC 3
- MAC 3.5
- MAC 4
- MAC 4.5
OVERALL LENGTH
- 101 MM
- 133 MM
- 148 MM
- 155 MM
- 160 MM
BLADE LENGTH
- 93 MM
- 110 MM
- 122 MM
- 133 MM
- 142 MM
DISTAL WIDTH
- 13 MM
- 14.5 MM
- 14.5 MM
- 14.5 MM
- 14.5 MM
LED Fiber Optic Handles
- LED technology provides up to 40% more light than conventional halogen bulbs
- Textured surface provides a non-slip grip for enhanced safety.
- Compatible with all ISO 7376 (Green System) blades.
- Available in three sizes: Medium / Adult, Penlight / Pediatric and Stubby.
LED Fiber Optic Handels – Specifications
SIZE
- C
- AA
- SHORT
NAME
- Medium / Adult Handle
- Penlight / Pediatric Handle
- Stubby Handle
POWER SOURCE
- LED 5 W
- LED 5 W
- LED 5 W
Clinical Applications
Operation Theatre
ICU & Emergency
Teaching Hospitals
Configure Your Fiber Optic Laryngoscope System
Select the blade and handle combination that best suits your clinical needs.
